Main features
- very solid and durable structure
- ergonomic design facilitating operation and handling
- pneumatically adjustable disc locks
- adjustable inflation pressure (3 levels) up to 10 bars (145 psi)
Set Contents
- TRUCK AIR TEST TRUCK
- 3 pairs of pressure plates: Pair 1: 17,5 inches, Pair 2: 19,5 inches, Pair 3: 22,5 inches
- Foot switch
- size
Basic technical specification
| Pneumatic system | |
| Required feed pressure | 6-10 bars (87-145 psi) |
| Maximum inflation pressure | 10 bar (145 psi) |
| Electric system | |
| Power supply | 380V |
| Engine power | 1.5 kW |
Operating dimensions
| Height | 200 cm |
| Width | 120 cm |
| Length | 240 cm |
| Weight | 2500 kg |
